The standard serial transmission parameters of the instrument are:
* Baud Rate 19200 Baud
* Parity None
* N. bit 8
* Stop bit 1
* Protocol Xon/Xoff
The data transmission speed may be changed by pressing the PROG key on the instrument to alter
the set-up parameter P3. The possible baud rates are: 19200, 9600, 4800, 2400, 1200, 600, 300.
The other transmission parameters are fixed.
All the commands given to the instrument must have the following structure:
XYcr where:
XY constitutes the command code
cr Carriage Return (ASCII 0D)
The command characters are exclusively upper case, the instrument replies with a “?” to any other
combination of characters sent, the instrument reply strings do not contain control characters (the
instrument does not send line-feed or carriage return characters to the terminal). Once a command
has been accepted it is possible to obtain repetition of the action by sending only - cr - to the instru-
ment; thus, for example, successive measurements of the same channel may be displayed simply
by pressing the return key on the terminal.
106
ENGLISH
COMMAND RESPONSE NOTES
SA
SB
SC
SI
AA
AG
AH
Xoff (ctrl-S)
Xon (ctrl-Q)
String of 19 characters containing value
and measuring unit channel A
As above channel B
As above channel A-B
PHOTO/RADIO/THERMOMETER DATA
LOGGER rev. Vx Rx
As above
Vx Rx
gg/mm/aa
Print channel A for example:
....2.15...W/m
2
....
Print channel B
Print channel A-B
Type of instrument
Type of instrument
Firmware Version
Firmware Date
Stop transmission
Resume transmission
