INSTRUCTIONS FOR CONNECTING DELTA OHM INSTRUMENTS TO A PC
WITH WINDOWS OPERATIVE SYSTEM
HARDWARE CONNECTION:
1) The measuring instrument must be switched off.
2) Connect the serial gate of the measuring instrument to a free serial gate on the PC
(COM1/COM2) using the special Delta Ohm CP RS232C cable.
Note: the CP RS232C cable ends in a female 25-pin connector; if your PC does not have a com-
patible connector, use the adapters normally found on the market to make the connection.
3) Turn the switch on the CP RS232C cable to COMPUTER 7 position.
SOFTWARE CONNECTION WITH WINDOWS 3.1:
A) Start WINDOWS.
B) Select ACCESSORIES (2 click).
C) Select TERMINAL and activate the communications program (2 click).
