12
M4 Allen Wrench Supplied
From Step 1 Section 2
Attach (1) Stabilizer Bar (Part K) to the assembly from step 1 section 2 using (2) Φ4x30 mm Metal Pins
(Part T), (2) M6x80 mm Bolts (Part M) and (2) M6 x 17mm Barrel Nuts (Part U).
GENTLY PULL THE LEFT AND RIGHT FRONT LEG APART. TO INSTALL THE STABILIZER
BAR - BE VERY CAREFUL NOT TO SCRATCH THE FINISH.
Use the Flat Head Screwdriver to hold the Barrel Nut in the proper alignment. Tighten with the M4
Allen Wrench.
K
K. Stabilizer Bar x 1
M
U
M. M6 x 80 mm Bolt x 2
M
U
PULL GENTLY
U
T
M
Step 2
Section 2: Toddler Bed Conversion
Parts and tools required to complete step.
U. M6 x 17mm Barrel Nut x 2
T. Φ4x30 mm Metal Pin x 2
To Next Page
