Delta 7886 User Manual

6
C. Left Rear
Leg x 1
G. Left Front
Leg x 1
D. Right Rear
Leg x 1
H. Right Front
Leg x 1
M4 Allen Wrench Supplied
Attach (1) Left Crib End (Part E) to (1) Left Rear Leg (Part C) and (1) Left Front Leg (Part G) using (1)
Φ4x30mm Metal Pins (Part T), (2) M6x45mm Bolts (Part P) and (3) M6x40mm Bolts (Part R). Tighten
with the M4 Allen Wrench. Use the Flat Head Screwdriver to hold the Barrel Nut in the proper alignment.
Repeat on the Right Crib End (Part F).
E
C
G
Left Crib End
NOTE: AFTER ASSEMBLY, THE “STEPPED HOLES” IN BOTH POSTS ARE ON THE SAME SIDE.
E. Left Crib
End x 1
F. Right Crib
End x 1
INSIDE
PRODUCT LABEL
OUTSIDE
WARNING LABEL
OUTSIDE
WARNING LABEL
PRODUCT LABEL
P. M6 x 45 mm Bolt x 4
R. M6 x 40 mm Bolt x 6
T
P
P
R
R
ON INSIDE FACE
Step 1
Section 1: Crib Assembly
Parts and tools required to complete step.
T. Φ4x30 mm Metal Pin x 2
