15
M4 Allen Wrench
Supplied
S. M6 x 18 mm Bolt x 4
V
V
V. Adapter Plate x 2
S
V
S
Step 2
Section 3: Full Size Bed Conversion
Parts and tools required to complete step.
Attach Adapter Plates (Part V) to bottom of
Rear Side Rail Legs using (4) M6x18mm
Bolts (Part S). Hand tighten bolts in place.
Adjust up or down to allow for connection to
Bed Rail. Adapter “Tabs” will keep Adapter
Plate from rotating.
Stand Headboard up. Attach to Bed Frame with
bolts and nuts (supplied by Bed Frame manufacturer).
Adapter Plates (Part V) can be adjusted up or
down to best suit Bed Frame. Tighten all bolts
once Bed Rail is adjusted.
Note: Bed Frames are not supplied with this system,
but can be purchased at mattress stores.
