Delta 7888 - Step 2: Attach Stabilizer Bar

12
Step 2
Section 2: Toddler Bed Conversion
Parts and tools required to complete step.
M4 Allen Wrench
Supplied
From Step 1
J. M6 x 45 mm Bolt x 2
L. Φ4x30 mm Metal Pin x 2
G
J
J
PULL GENTLY
PULL GENTLY
Attach the Stabilizer Bar (Part G) to the assembly from step 1 using (2) Φ4x30 mm Metal Pins (Part L)
and (2) M6x45 mm Bolts (Part J). Tighten with the M4 Allen Wrench.
G. Stabilizer Bar x 1
G
J
L
BOTH ENDS
