PARTS: HARDWARE AND TOOLS.
5
M. Adapter Plate x 2
M4 Allen Wrench Supplied
K. M6 x15 mm Bolt x 4
L. Φ4x30 mm Metal Pin x 4
J. M6 x 45 mm Bolt x 12
No drills necessary. Do not
use power screwdriver.
Part # 5466
Part # 5460
Part # 5493
Part # 1177
Part # 5686
