PARTS: MAKE SURE THAT ALL PRE-ASSEMBLED PARTS ARE TIGHT.
A. Top Rail x 2
C. Left Crib End x 1
D. Right Crib End x 1
F. Mattress Support x 1
4
E. Front Side x 1
B. Back Side x 1
G. Stabilizer Bar x 1
POUCH ATTACHED TO MATTRESS SUPPORT
- KEEP INSTRUCTIONS IN THIS POUCH
AFTER ASSEMBLY.
WARNINGS RELATED TO THE SAFE USE OF
THIS CRIB ARE PRINTED ON THE POUCH.
H. Guardrail x 1
Part # 14892
C3. Left Back Post
D3. Right Back Post
C1. Left End Panel
D1. Right End Panel
C2. Left Front Post
D2. Right Front Post
N. M6 x 65 mm Bolt x 10
Used to factory assemble Parts C&D
as originally shipped
To Next Page
