Delta A08184 - Parts List

23- ENG
A08184
PARTS LIST
Key Part
No. Number Description
1 ACG-408 Fastener Assembly (2)
2 AC-0376 Mini Shroud
3 91895680 Screw 1/4-20 x 3/4 (2)
4 ACG-18 Cup, Saddle Mount (2)
5 CAC-60 Shoulder Bolt (2)
6 AC-0774 Isolator (3)
8 AC-0605-1 Outlet Tube
9 SSP-7811 Nut Sleeve Assembly 1/4"
10 Z-D23004 Gauge (2)
11 SSP-6021 Reducer Bushing 1/8-1/4NPT
14 Z-D26611 Pressure Switch
15 D24888 Nipple 1/4-18 NPT x 2-1/2
17 TIA-4150 Safety Valve
18 D26615 Cord Assembly
19 D23138 Wheel - 9" (2)
20 AC-0609 Handle
21 SS-1286 Nipple 1/4-18 NPT
22 D21172 Screw (4)
23 SSF-8080-ZN Nut Hex 3/8-16
UNC - 2B (2)
24 CAC-4296-1 Regulator
25 D26899 Adaptor
26 AC-0630 Pressure Relief Tube
27 AC-0631 Check Valve
28 SSP-7813 Nut Sleeve Assembly 3/8"
29 SST-107 Rubber Bumper (2)
30 SSF-630 Bumper Screw (2)
31 SSP-7821-1 Tube Nut
32 SSG-3105 O-Ring
33 Z-D26196 Tank
Not Shown
D23000 Drain Valve
