Chapter 13 IO-Link Communication Module AS04SIL
13-5
13
 Electrical Specifications
Item Specifications
Power supply to
device in IO-Link
mode or SIO (DI)
mode
Rated voltage
24VDC (20.4VDC~ 28.8VDC) (-15%~+20%)
Max. load
current
0.2A/port
Short-circuit
protection
Yes
Digital inputs in SIO
(DI) mode
Internal I/O
common
NPN, PNP
Input voltage/
current
24VDC, 5mA
ON voltage
>15VDC
OFF voltage
<5VDC
Input filter time
No filter, 1ms (default), 2ms, 4ms, 8ms, 16ms, 32ms, 64ms, 128ms, 256ms
Digital outputs in
SIO (DO) mode
Internal I/O
common
NPN, PNP
Output voltage/
current
24VDC (20.4VDC~ 28.8VDC),0.1A/port
Short-circuit
protection
Yes
Leakage current
<0.1mA
Residual voltage
<1.5VDC
Digital inputs for
Pin2 in IO-Link mode
Internal I/O
common
NPN, PNP
Input voltage/
current
24 VDC, 2mA
ON voltage
>15VDC
OFF voltage
<5VDC
Input filter time
No filter, 1ms (default), 2ms, 4ms, 8ms, 16ms, 32ms, 64ms, 128ms, 256ms
Power consumption
0.8W
Weight
133g
