Delta AS00SCM-A User Manual

AS Series Module Manual
11-80
11
11.5.4.3.4. Status Word and Control Word of AS01DNET (RTU)
The start input address and start output address in the mapping areas of AS01DNET (RTU) are used as the status word
and control word of AS01DNET (RTU) respectively with the detailed explanation in the following table.
 Control word of AS01DNET(RTU)
Bit
Status value
Description
bit0
~
bit2
000
Make no control setting for the operation of AS01DNET(RTU)
001
Set AS01DNET(RTU) to RUN mode
010 Set AS01DNET(RTU) to STOP mode
Other Reserved
bit3
0
Reserved
1
Restart AS01DNET (RTU)
bit4
0/1
Reserved
bit5
0/1
Reserved
bit6
0/1
Reserved
bit7
0/1
Reserved
bit8
0/1
Reserved
bit9 0/1 Reserved
bit10 0/1 Reserved
bit11 0/1 Reserved
bit12
0/1
Reserved
bit13
0/1
Reserved
bit14
0/1
Reserved
bit15
0/1
Reserved
 Status word of AS01DNET(RTU)
Bit
Status value
Description
bit0
0
AS01DNET (RTU) in RUN state
1
AS01DNET (RTU) stops.
bit1
0/1
Reserved
bit2
0 No error occurs in I/O modules.
1 An error occurs in I/O modules.
bit3 0/1 Reserved
bit4
0
Current connection matches the configuration.
1
Current connection is inconsistent with the configuration.
bit5
0
AS01DNET (RTU) works normally.
1
The voltage of the power supply for AS01DNET (RTU) is too low.
bit6
0/1
Reserved
bit7
0
AS01DNET (RTU) works normally.
1
The number of points/ modules exceeds allowed range.
bit8 0/1 Reserved
bit9 0/1 Reserved
bit10
0/1
Reserved
bit11
0/1
Reserved
bit12
0/1
Reserved
