4.5.4
Powe
r Consump
tion
The follo
wing table lists the power cons
umption for
AS Series m
odules.
Classificatio
n
Mod
el name
Internal po
wer
consumption
(m
A)
Internal po
wer
consumption
(W)
External pow
er
consumption
(W)
CPU module
AS332P
-A
150
3.6
N/A
AS332T
-A
150
3.6
N/A
AS324MT
-A
150
3.6
N/A
AS320P
-B
150
3.6
N/A
AS320T
-B
150
3.6
N/A
AS300N
-A
125
3
N/A
AS228
T
-A
150
3.6
N/A
AS228P
-A
150
3.6
N/A
AS228R
-A
190
4.56
N/A
AS218TX
-A
180
4.32
N/A
AS218PX
-A
180
4.32
N/A
AS218RX
-A
200
4.8
N/A
AS132T
-A
11
0
2.64
N/A
AS132P
-A
11
0
2.64
N/A
AS132R
-A
160
3.84
N/A
AS148T
-A
125
3
N/A
AS148P
-A
125
3
N/A
AS1
48R
-A
200
4.8
N/A
AS164T
-A
140
3.36
N/A
AS164P
-A
140
3.36
N/A
AS164R
-A
240
5.76
N/A
Digital I/O
module
AS08AM10N-A
20
0.
5
N/A
AS08AN01T
-A
30
0.72
N/A
AS08AN01P
-A
60
1.4
N/A
AS08AN01R
-A
70
1.7
N/A
AS16AM10N-A
20
0.5
N/A
AS16AP1
1T
-A
30
0.7
N
/A
AS16AP1
1P-A
30
0.7
N/A
AS16AP1
1R-A
80
1.9
N/A
AS16AN01T
-A
60
1.4
N/A
AS16AN01P
-A
60
1.4
N/A
AS16AN01R
-A
140
3.4
N/A
AS32AM10N-A
20
0.48
N/A
AS32AN02T
-A
30
0.72
N/A
AS64AM10N-A
30
0.72
N/A
AS64AN02T
-A
60
1.44
N/A
Analog I/O
module
AS04AD-A
50
1.2
2.16
AS08AD-B
50
1.2
2.5
AS08AD-C
50
1.2
2.5
AS04DA
-A
50
1.2
2.64
AS06XA-A
50
1.2
2.16
AS02ADH-A
50
1.2
2
T
emperatu
re
measurement
module
AS04RTD-A
30
0.75
2
AS06RTD-A
30
0.75
2
AS04TC
-A
30
0.75
2
AS08TC
-A
30
0.75
2
Load cell
AS02LC
-A
30
0.75
3
