Enable BOOTP Enables the BOOTP to assign an IP address for the selected item.
Enable DHCP Enables the DHCP to assign an IP address to the selected item.
Disable BOOTP/DHCP
Disables the BOOTP/DHCP on the device; the device does not request an IP
addresses from the server.
Steps to set the IP address:
1. MAC address: find the MAC address on the EIP device. The MAC address uniquely identifies the device.
2. Open the DHCP Server
HWCONFIG : Click Tool and then click DHCP Server.
The IP Manager can be the BOOTP/DHCP Server, receiving IP address requests from devices. The IP
Manager window is shown below.
Send Quote Requests to info@automatedpt.com
Call +1(800)985-6929 To Order or Order Online At Deltaacdrives.com
Send Quote Requests to info@automatedpt.com
Call +1(800)985-6929 To Order or Order Online At Deltaacdrives.com

Table of Contents

Questions and Answers:

Delta AS218PX-A Specifications

General IconGeneral
ModelAS218PX-A
SeriesAS Series
Input Voltage24 VDC
Output Voltage24 VDC
Digital Input8 points
Digital Output8 points
Output TypeTransistor
Communication InterfaceRS-232, RS-485, Ethernet
Output Current0.5 A per point
ProtectionIP20
Weight200 g
TypePLC
Operating Temperature0°C to 55°C
Dimensions90 x 60 x 90 mm
Storage Temperature-25°C ~ 70°C (-13°F ~ 158°F)
Humidity5% ~ 95% RH, non-condensing
