Delta AS218TX-A User Manual

Number
Name
Description
RTU mode:

NS LED
OFF: no power or duplicate ID check has not been
completed.
Green light blinking every 0.5 seconds: the connection
to the DeviceNet network failed.
Green light ON: online; the connection to the DeviceNet
network is normal.
Red light blinking every 0.5 seconds: I/O connection
timeout between AS01DNET (RTU) and DeviceNet master
Red light ON: Network trouble, duplicate node ID, no
network power or Bus-OFF.

MS LED
OFF: no power
Green light blinking every 0.5 seconds:
- AS01DNET (RTU) is waiting for the I/O data from
DeviceNet master.
- No I/O data transmission between AS01DNET(RTU) and
DeviceNet master
- The PLC connected to DeviceNet master is in STOP state.
Green light ON: normal transmission of I/O data between
AS01DNET (RTU) and DeviceNet master
Red light blinking every 0.5 seconds: no network power
supply; configuration error; module alarms.
Red light ON: hardware error
3
Address switch
Setting up the address
4 Function switch
Setting up the funcitons, including the work mode and baud rate
of
DeviceNet network
5
DeviceNet communication
port
Connects the modules via DeviceNet communication.
Use AS01DNET-A connector for wiring.
6
Mode switch
(RTU/DNET;
Master/Slave)
Master/Slave mode: the port does not need an external
24VDC power supply connected
RTU mode: the power input port of the network module is
required to connect an external 24VDC power supply only.
You can connect
7
Left-side extension port
Connects the modules
8
Label
Nameplate
9
Right-side extension port
Connects the modules
10
Input for supplying power
to remote modules
Power supply for the remote module
