Wiring the External Terminal Module UB-10-OR16A
For cables that can only be connected to the cables of group #1, see below.
Output form
Relay
Voltage specifications
Less than 250 VAC, 30 VDC, 2 A
Length
UC-ET010-24D(1M)(28AWG)
UC-ET020-24D(2M)
UC-ET030-24D(3M)
(28AWG)
(28AWG)
Length:
39 40
1 2
500+10mm
-
19 20
1 2
19 20
1
2
#1
#2
C0 Y0.5Y0.0 Y0.1 Y0.2 Y0.3 C1 Y0.4 Y0.6 C3Y0.7
C2
Y0.8 Y0.9 Y0.10 Y0.11
Y0.12
Y0.14
Y0.15Y0.
13
GND
+24V
Note: UB-10-OR16A can be used with AS Series and DVP Series. The indications on the UB-10-OR16A board
is for DVP Series. For the definitions of terminal connections for AS Series, you can see the reference table
below. Or refer to the enclosed sticker for AS Series.
Wiring the External Terminal Module UB-10-OT32A
Output form
Transistor-T (sinking)
Voltage specifications
5 to 30 VDC, 0.1 A
Length
39 40
39 40
1 2
1 2
UC-ET010-24B(1M)
UC-ET020-24B(2M)
UC-ET030-24B(3M)
Length:
Y0.0
Y0.1
Y0.14
Y0.15
Y0.2
Y0.3
Y0.4
Y0.5
Y0.6
Y0.7
Y0.8
Y0.9
Y0.10
Y0.11
Y0.12
Y0.13
Y1.0
Y1.1
Y1.14
Y1.15
Y1.2
Y1.3
Y1.4
Y1.5
Y1.6
Y1.7
Y1.8
Y1.9
Y1.10
Y1.11
Y1.12
Y1.13
C0
Upper
row
C0
Lower
row
