5.4.5 Starting Addresses for Network Modules
HWCONFIG automatically assigns consecutive input and output data registers starting from D28000 to a
network module in ISPSoft according to the number of registers defined for the network module.
• SCM, as a general COM communication module:
Communication status and communication method; the input device range occupies 20 data registers,
and the output device range occupies 20 data registers.
• Remote module SCM: the input device range and output device range each occupy 10 data registers.
• AS01DNET-A: when selecting the COM communication mode, its communication status and
communication method: the input device range occupies 20 data registers, and the output device range
occupies 20 data registers.
