Class
Attribute
Name
Access
Rule
Data Type Values Description
Port Type UINT H’04 EtherNet/IP, refer to the following *1
Port Number UINT H’01 Identifies each communication port
When Instance = 1, the Instance Attributes are listed below.
Instance
Attribute
Name
Access
Rule
Data Type Values Description
H’01 Port Type Get UINT H’04 EtherNet/IP, refer to the following *1
H’02 Port Number Get UINT H’01 Identifies each communication port
H’03
Link Object
Get
STRUCT of --
Identifies Object attached to this
port. Path length + Link Path
Path Length UINT -- Path length
Link Path EPATH -- Path segment
H’04 Port Name Get
SHORT_
STRING
EIP1 Name of the communication port
H’07
Port Number and
Node Address
Get EPATH 01 01
Communication port number and
node number of this device on port.
*1 Communication Port Type
Communication Port Type Description
1 Self-defined
2 ControlNet
3 ControlNet Redundant
4 EtherNet/IP
5 DeviceNet
201 Modbus/TCP
203 SERCOS III
