 AS100 Series: Electrical specifications for the inputs. The signals passing through the inputs are
24 VDC signals.
Model
Item
AS164T-A
AS164P-A
AS164R-A
AS148T-A
AS148P-A
AS148R-A
AS132T-A
AS132P-A
AS132R-A
Number of inputs
32
(X0.0~X0.15)
(X1.0~X1.15)
24
(X0.0~X0.15)
(X1.0~X1.7)
16
(X0.0 ~ X0.15)
Terminal connector
type
Removable screw-type terminal blocks
Input type
Digital input
Input form
Direct current (sinking or sourcing)
Input voltage/ current
24 VDC, 5 mA
Action
level
OFF→ON
>15 VDC
ON→OFF
<5 VDC
Response
time
OFF→ON
X0.0~X0.7: < 2.5 μs
X0.8~X0.15: <25 μs
X1.0~X1.15: < 500 μs
ON→OFF
X0.0~X0.7: < 2.5 μs
X0.8~X0.15: <25 μs
X1.0~X1.15: < 500 μs
Maximum input
frequency
X0.0~X0.7: 200 kHz
X0.8~X0.15: 20 kHz
X1.0~X1.15: 1 kHZ
Input impedance
X0.0~X0.7: 3.9 k Ω
X0.8~X0.15; X1.0~X1.15: 5.6 k Ω
Input signal
Voltage direct input
Sinking: The inputs are NPN transistors whose collectors are open collectors.
Sourcing: The inputs are PNP transistors whose collectors are open collectors.
Digital input isolation
500 VAC
Input display
When the optocoupler is driven, the input LED indicator is ON.
 AS100 Series: Electrical specifications for the outputs
Model
Item
AS164R-A
AS148R-A
AS132R-A
AS164T-A
AS148T-A
AS132T-A
AS164P-A
AS148P-A
AS132P-A
Number of outputs
AS132R/T/P-A: 16 outputs (Y0.0~Y0.15)
AS148R/T/P-A: 24 outputs (Y0.0~Y0.15) (Y1.0~Y1.7)
AS164R/T/P-A: 32 outputs (Y0.0~Y0.15) (Y1.0~Y1.15)
Terminal connector
type
Removable screw-type terminal blocks
Output form
Relay
Relay
Relay
Voltage / current
240 VAC/24 VDC
5~30 VDC
Leakage current
0uA
<10uA
Max. inrush current
NA
Transistor-T (sinking): 0.8 A
Transistor-P (sourcing): 7.2 A
(Tested condition: Ta = 25
0
C, V
DS
= 30VDC and pulse
duration = 1ms)
Maximum
load
Resistan
ce
2A/output, 5A/COM 0.5A/output, 2A/COM
Inductan
ce
Life cycle curve*
2
15W (30 VDC)
