Delta AS218TX-A User Manual

Functional specifications
Analog-to-digital
conversion
Centigrade (°C) Fahrenheit (°F) Input impedance
Rated input range
*1
Type J: -100°C~1200°C
Type K: -100°C~1,350°C
Type R: 0°C~1,750°C
Type S: 0°C~1,750°C
Type T: -150°C~400°C
Type E: -150°C~980°C
Type N: -150°C~1,300°C
Type B: 200°C~1,800°C
Type C: 0°C~2,320°C
Type U: -200°C~600°C
Type L: -200°C~900°C
Type TXK: -200°C~800°C
Type J: -148°F~2,192°F
Type K: -148°F~2,462°F
Type R: 32°F~3,182°F
Type S: 32°F~3,182°F
Type T: -238°F~752°F
Type E: -238°F~1,796°F
Type N: -238°F~2,372°F
Type B: 392°F~3,272°F
Type C: NA
Type U: -328°F~1,112°F
Type L: -328°F~1,652°F
Type TXK: -328°F~1,472°F
±100mV
Maximum
Measurable Range
*2
Type J: -210°C~1200°C
Type K: -250°C~1,350°C
Type R: -50°C~1,760°C
Type S: -50°C~1,760°C
Type T: -250°C~400°C
Type E: -250°C~1000°C
Type N: -250°C~1,300°C
Type B: 20°C~1,800°C
Type C: 0°C~2,320°C
Type U: -200°C~600°C
Type L: -200°C~900°C
Type TXK: -200°C~800°C
Type J: -346°F~2,192°F
Type K: -418°F~2,462°F
Type R: -58°F~3,200°F
Type S: -25°F~3,200°F
Type T: -418°F~752°F
Type E: -418°F~1,832°F
Type N: -418°F~2,372°F
Type B: 68°F~3,272°F
Type C: NA
Type U: -328°F~1,112°F
Type L: -328°F~1,652°F
Type TXK: -328°F~1,472°F
±100mV
Average function
Range: 1~100
Self-diagnosis
Disconnection detection
*1: If any of these limits are exceeded, device functionality should not be assumed, damage may occur
and reliability may be affected.
*2: If the to be measured temperature exceeds the upper/lower limit, it only shows the maximum /
minimum value.
