(6) Specifications
Model
DOP-B05S111
LCD
MODULE
Display Type
5.6” TFT LCD
(65536 colors)
Resolution
320 x 234 pixels
Backlight
LED Back Light (less than 20,000 hours half-life at 25
o
C)
(Note 1)
Display Size 113.28 x 84.70mm
Operation System Delta Real Time OS
MCU 32-bit RISC Micro-controller
NOR Flash ROM
Flash ROM 128 MB
(OS System: 30MB / Backup: 16MB / User Application: 82MB)
SDRAM
64Mbytes
Backup Memory 16Mbytes
Sound
Effect
Output
Buzzer
Multi-Tone Frequency（2K ~ 4K Hz）／85dB
AUX
N/A
Ethernet Interface
N/A
USB 1 USB Host
(Note 2)
Ver 1.1 / 1 USB Slave Ver 2.0
Memory Card N/A
Serial
COM
Port
COM1 RS-232 (supports hardware flow control)
COM2
RS-232／RS-485
COM3
RS-422／RS-485
Function Key N/A
Perpetual Calendar
(RTC)
Built-in
Cooling Method Natural air circulation
Safety Approval
CE／UL
(Note 3)
／KCC
(Note 3)
Waterproof Degree
IP65／NEMA4
Operation Voltage
(Note 4)
DC +24V（-10% ~ +15%）(please use isolated power supply)
Voltage Endurance
AC500V for 1 minute (between charging (DC24V terminal) and FG
terminals)
Power
Consumption
(Note 4)
3.0W
Backup Battery 3V lithium battery CR2032 x 1
Backup Battery Life
It depends on the temperature used and the conditions of usage,
about 3 years or more at 25
o
C.
Operation Temp.
0
o
C ~ 50
o
C
Storage Temp.
-20
o
C ~ +60
o
C
Ambient Humidity
10% ~ 90% RH [0 ~ 40
o
C], 10% ~ 55% RH [41 ~ 50
o
C]
Pollution Degree 2
Vibration
IEC 61131-2 compliant 5Hz≦f＜8.3Hz = Continuous: 3.5mm, 8.3Hz≦f≦
150Hz = Continuous: 1.0g
Shock
IEC 60068-2-27 compliant 15g peak for 11 ms duration, X, Y, Z directions
for 6 times
Dimensions
(W) x (H) x (D) mm
184 x 144 x 50
Panel Cutout
(W) x (H) mm
172.4 x 132.4
Weight Approx.670g
NOTE
1) The half-life of backlight is defined as original luminance being reduced by 50% when the maximum driving current is supplied to HMI.
The life of LED backlight shown here is an estimated value under 25
o
C normal temperature and humidity conditions.
2) USB Host port can provide up to 5V/ 500mA of power.
3) Some models are in the process of application to UL and KCC certification. For more information, please consult our distributors.
4) The value of the power consumption indicates the electrical power consumed by HMI only without connecting to any peripheral
devices. In order to ensure the normal operation, it is recommended to use a power supply which the capacity is 1.5 ~2 times the value
of the power consumption.
5) The content of this quick start may be revised without prior notice. Please consult our distributors or download the most updated
version at http://www.delta.com.tw/ia/.
