Delta DVP-SA2 User Manual

3. Instruction Set
3-449
API Mnemonic Operands Function
Controllers
ES2/
EX2
SS2
SA2
SX2
SE
149 MEMW P
Writing the data into
the file register
Type
OP
Bit Devices Word devices Program Steps
X Y M S K H KnX KnY KnM KnS T C D E F
7 steps
The 32-
bit instruction and
DVP-SS2 are not
supported.
S
*
m
*
*
*
n
*
*
*
PULSE
16-bit
32-bit
ES2/
EX2
SS2
SA2
S
X2 SE
ES2/
EX2
SS2 SA2 SX2 SE
ES2/
EX2
SS2
SA2 SX2 SE
Operands:
S: Initial source device (The data register is between D2000 and D9999.)
m: File register into which the data is written.
n: Number of data (The number of data is between K1 and K100.)
Explanations:
1. The 32-bit instruction is not supported.
2. If m, D, or n is not within the range, an operation error occurs, the instruction is not executed,
M1067 and M1068 is ON, and the error code in D1067 is H’0E1A.
3. Owing to the fact that the file registers take flash ROM as the memories, 100 words at most can
be written into the file registers, and only when the conditional contact turns from OFF to ON
can the data be written into the file registers once. Note: The data only can be written into the
file registers 100,000 times. Please use them with care.
4. The range of supported operands m and n:
Models
Firmware version
Operand m
Operand n
SA2/SX2
V2.40~V3.00
K0 ~ K4999
K1~K100
V3.02 and later
K0 ~ K7999
K1~K100
ES2/EX2
V2.80~3.44
K0 ~ K4999
K1~K100
V3.46 and later
K0 ~ K7999
K1~K100
ES2-E
Should work with a
memory card
V1.08 and later K0 ~ K7999 K1~K100
SS2/SE
NOT supported
ES2-C
NOT supported
Program Example:
1. Use MEMW to write the data from the 100 data registers starting from D2000 to the file registers
starting from the tenth file register.
2. When X0 turns from OFF to ON, the instruction is executed once.
MEMW D2000 K10 K100
X0
MEMW D2000 K10 K100
X0
