Appendix C Inforamation about TP Series Text Panels
C-29
Classification API
Mnemonic
PULSE
Function
16 bits
32 bits
188
MBS
–

Matrix bit shift
189
MBR
–

Matrix bit rotate
190
MBC
–

Matrix bit status count
Contact Type
Logic Operation
215
LD&
DLD&
–
S
1
& S
2
216
LD|
DLD|
–
S
1
| S
2
217
LD^
DLD^
–
S
1
^ S
2
218
AND&
DAND&
–
S
1
& S
2
219
AND|
DAND|
–
S
1
| S
2
220
AND^
DAND^
–
S
1
^ S
2
221
OR&
DOR&
–
S
1
& S
2
222
OR|
DOR|
–
S
1
| S
2
223
OR^
DOR^
–
S
1
^ S
2
Contact Type
Comparison
224
LD=
DLD=
–
S
1
＝
S
2
225
LD>
DLD>
–
S
1
＞ S
2
226
LD<
DLD<
–
S
1
＜
S
2
228
LD<>
DLD<>
–
S
1
≠ S
2
229
LD<=
DLD<=
–
S
1
≦
S
2
230
LD>=
DLD>=
–
S
1
≧ S
2
232
AND=
DAND=
–
S
1
＝
S
2
233
AND>
DAND>
–
S
1
＞ S
2
234
AND<
DAND<
–
S
1
＜
S
2
236
AND<>
DAND<>
–
S
1
≠ S
2
237
AND<=
DAND<=
–
S
1
≦
S
2
Contact Type
Comparison
238
AND>=
DAND>=
–
S
1
≧
S
2
240
OR=
DOR=
–
S
1
＝
S
2
241
OR>
DOR>
–
S
1
＞
S
2
242
OR<
DOR<
–
S
1
＜
S
2
244
OR<>
DOR<>
–
S
1
≠ S
2
Contact Type
Comparison
245
OR<=
DOR<=
–
S
1
≦
S
2
246
OR>=
DOR>=
–
S
1
≧
S
2
Specific Bit
Control
266
BOUT
DBOUT
–
Output specified bit of a word
267
BSET
DBSET
–
Set ON specified bit of a word
268
BRST
DBRST
–
Reset specified bit of a word
269
BLD
DBLD
–
Load NO contact by specified bit
270
BLDI
DBLDI
–
Load NC contact by specified bit
271 BAND DBAND –
Connect NO contact in series by
specified bit
272 BANI DBANI –
Connect NC contact in series by
specified bit
273 BOR DBOR –
Connect NO contact in parallel by
specified bit
274 BORI DBORI –
Connect NC contact in parallel by
specified bit
Floating-Point
Contact Type
Comparison
275
–
FLD=
–
S
1
＝ S
2
276
–
FLD>
–
S
1
＞
S
2
277
–
FLD<
–
S
1
＜ S
2
278
–
FLD<>
–
S
1
≠ S
2
279
–
FLD<=
–
S
1
≦ S
2
280
–
FLD>=
–
S
1
≧
S
2
