Chapter 2 Settings and Measurements
LD-E Operation Manual
2-7
Median filter
setting
Median filter window frame setting:
“
”: window frame size 1, “ ”: window frame size,
“
”: window frame size 5, “ ”: window frame size
7, “
”: window frame size 9, “ ”: window frame
size 11, “
”: window frame size 13, “ ”: window
frame size 15
Output setting
Select the action mode of control output
“
”: when light is on, “ ”: when not receiving light
on
Detection
output setting
Detection output setting:
“
”: General teaching mode
“
”: Single point teaching mode
“
”: Two point teaching mode
“
”: Three point teaching mode
Hysteresis
setting
<LD-500E
、
LD-220E
、
LD-100E >
Hysteresis setting
The maximum limitation of 1_SL is 2_SL + Hys
The minimum limitation of 1_SL is 1_SL - Hys
External input
setting
External input setting:
“
”: no function, “ ”: zero, “ ”: laser off
“
”: update data only when triggered
Timer setting
Timer setting
The timer setting interval is 0~1000ms
“
”: no timing, “ ” : delay action
“
”: postpone disconnecting, “ ”: single triggger
(specific introduction can refer to timer setting)
Exposure
setting
Exposure energy setting:
“
”: Automatically adjust the received energy
according to non-reflective objects. Press
to view
the current percentage of energy.
“
”: Manually adjust the received energy. Press
to set the received energy percentage.
Adjust the
negative limit
Output to set the negative limit:
The adjustment range is the minimum value of the
measurable range.
Adjust the
positive limit
Output to set the positive limit:
The adjustment range is the maxmum value of the
measurable range.
Baud rate
setting
Baud rate setting:
“
”: 115200 bps, “ ”: 57600 bps, “ ”: 38400
