Chapter 3 Software Operation
LD-E Operation Manual
◎ Real-time graphics operation area
Station No.
Set the station number of the laser displacement, and only one data can
be displayed at a time.
Display the absolute displacement of the laser
Storage quantity setting
Can store the relationship between time and location
Start saving
Start
Start position measurement and draw graphics
Measuring range
Graphic display measurement range size
