Chapter 3 Software Operation
LD-E Operation Manual
◎ Wave operation area
Station No.
Set the station number of the laser displacement er, and only one data can
be displayed at a time.
Display wave weight position
Shutter Level
Show exposure
Exposure setting
Can be set to use manual or automatic exposure, manual exposure can set
the exposure level (0~100)
Start
Start measuring
Capture mode
Check: Quick capture mode (after firmware V1.00.00)
X-Y axis range
adjustment
The range can be adjusted according to the monitoring interval.
X-Y axis range adjustment
Capture mode
Exposure setting
To Next Page
