Delta MultiChoice 13/14 Series Installation Instructions

RP41589s
Showerhead
Cabeza de Rogadora
Pomme de Douche
RP6025s
Shower Flange
Pestaña de la Rogadora
Collerette
RP46074
Valve Cartridge
Válvula de Cartucho
Cartouche
RP6023s
Shower Arm
Brazo de la Rogadora
Tuyau de Pomme de Douche
RP23336
O-Ring
Anillo "O"
Joint Torique
RP29569
Spacer
Separadores
Piéce D'espacement
RP19809s
Escutcheon
Roseta
Rosace avec Orifice
RP196s
Trim Screws/Atornillos de
Franja/Vis de Finition
RP12630s
For Longer Screws
Para Tornillos Más Grandes
Pour Vis Plus Longues
RP51303s
Tub Spout/Pull-Up Diverter
Tubo de Salida para Bañera/
Botón Desviador de Alzar
Bec/avec dérivation à tirette
RP51304s
Handle Assembly
Ensamble de la Manija
Poignée
RP25620
Set Screw
Tornillo de Ajuste
Vis de Calage
T14038, T14238 & T14438 Models / Modelos / Modèles
RP26853
Wrench
Llave
Clée
RP4993
Seats & Springs
Asientos y Resortes
Sièges et Ressorts
RP14414
O-Rings
Anillos "O"
Joints Toriques
s Specify Finish
Especifíque el Acabado
Précisez le Fini
RP50879s
Trim Sleeve
Manga de Franja
Manchon de Finition
20
Refer to page 16 for more information. / Consulte con la página 16 para más información. /
Pour obtenir de plus amples renseignements, reportez-vous à la page 16.
RP53237s
Tub Spout/Non Diverter
Tubo de Salida para Bañera/Sin Desviador
Bec/Sans Dérivation
RP46384s
Showerhead
Cabeza de Rogadora
Pomme de Douche

Delta MultiChoice 13/14 Series Specifications

General

Series	MultiChoice 13/14 Series
Valve Type	Pressure Balance
Material	Brass
Connection Size	1/2 inch
Connection Type	NPT
Installation	Wall mount
Handle Style	Lever
ADA Compliant	Yes
Flow Rate	1.75 GPM
Number of Handles	1
Valve Included	Yes
WaterSense Certified	Yes
Hand Shower Included	No
Warranty	Limited Lifetime Warranty
Finish Options	Chrome, Stainless, Venetian Bronze
Cartridge	Pressure Balance Cartridge
