Delta MultiChoice 14 Series - Page 2

10/20/2020
107528 Rev. D
1
MultiChoice
®
Valve Trim
Installation Instructions
Owners Manual
13/14 Series
Write purchased model number here.
X00107528
You May Need
13/14
Series
13/14
Series
13/14
Series
Table of Contents:
Warranties ................................................................................... Page 2
Installation Instructions ............................................................... Pages 3 - 12
Clean and care ............................................................................ Page 12
Maintenance ............................................................................... Page 12
Cartridge Summary Reference Sheet ......................................... Page 13
For additional replacement parts, visit www.deltafaucet.com
CAUTION: This system/device must be set by the
label provided and apply or attach the label to
installer to ensure safe, maximum temperature.
the back side of the closest cabinet door and
Any change in the setting may raise the discharge
the warning label to the water heater. Leave
temperature above the limit considered safe and
this Instruction Sheet for the owner’s/user’s
may lead to hot water burns.
reference.
NOTICE TO INSTALLER: CAUTION! – As the
WARNING: This pressure balanced or
installer of this valve, it is your responsibility
thermostatic bath valve is designed
to properly INSTALL and ADJUST this valve
to minimize the effects of outlet water
per the instructions given. This valve does
temperature changes due to inlet pressure
not automatically adjust for inlet temperature
changes, commonly caused by dishwashers,
changes, therefore, someone must make the
washing machines, toilets and the like. It may
necessary Rotational Limit Stop adjustments
not provide protection from hot water burns
at the time of installation and further adjustments
when there is a failure of other temperature
may be necessary due to seasonal water
controlling devices elsewhere in the plumbing
temperature change. YOU MUST inform the
system, if the rotational limit stop is not
owner/user of this requirement by following the
properly set or if the hot water temperature is
instructions. If you or the owner/user are unsure
changed after the settings are made or if the
how to properly make these adjustments please
water inlet changes due to seasonal changes.
refer to page 6 and if still uncertain, call us at
WARNING: Do not install a shut-off device on
1-800-345-DELTA.
either outlet of this valve. When this type of
After installation and adjustment, you must affix
device shuts off the water flow, it can defeat
your name, company name and the date you
the ability of the valve to balance the hot and
adjusted the Rotational Limit Stop to the caution
cold water pressures.
107528
