Delta NC311A-MS-A

English-4
Accessories
Fittings
NC300A-MI-A_
NC300A-MS-A_
NC311A-MS-A_
NC310A-MS-A_
NC200A-MI-A_ Purpose
One 3-pin connector
● ● ● 24 V
DC
power supply
One terminal resistor
● ● ● DMCNET
Eight sets of M3
screws and nuts
● ● ●
Securing to the
machine
Two sets of 15-pin
male connectors
with fittings
● ● MPG and SPINDLE
One male and
one female 15-pin
connectors with
two sets of fittings
● MPG and SPINDLE
One female 15-pin
connector with fittings
● ● AXIS
One 5-pin connector
●
The X output contact of
the secondary panel
One 3-pin connector
●
The Y output contact of
the secondary panel
Two 6-pin connectors
●
HSI and REMOTE I/O
*1
One 2-pin connector
●*2 ●*3
The 24 V
DC
power to
the secondary panel
Note:
1. HSI: The connectors of G31 high speed and external emergency stop; REMOTE I/O: High-speed
Serial I/O.
2. For Cycle Start and Feed Hold keys on the secondary panel.
3. For I/O on the secondary panel.
