Using the zero-lock mechanism
The riflescope is equipped with the „ZeroLock” mechanism that
allows the user to set a lock for the vertical adjustment turret
for specific settings - most often after zeroing the riflescope for
a given shooting distance, e.g. 100m. This mechanism sets a hard
stop on the elevation zero, so the user cannot accidentally be
a whole turn of elevation out when dialling back to zero after
taking a longer shot that required multiple turns of elevation on
the turret.
Unscrew the ring on the top of the turret (fig 5). Then, using a
1.5mm Allen key, loosen the three lock screws located on the
side of the „ZeroLock” locking ring (Fig. 6). After zeroing the
riflescope set the locking ring and fix it by tightening the three
counter screws. Be careful not to change the position of the
turret and then set turret scale so that the „0” point aligns with
the start marker. Finally, replace and tighten the turret scale.
Fig. 6
