VFD-B Series
DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED
8-10
Parameters Explanation Settings
Factory
Setting
29: Jog Fwd/Rev command
30: External Reset (NC)
31: Source of second frequency
command enabled
32: Source of second operation
command enabled
33: One shot PLC
34: Proximity sensor input for simple
Index function
35: Output Shutoff Stop (NO)
36: Output Shutoff Stop (NC)
00: No functions
04-10
Digital Terminal Input
Debouncing Time
1 to 20m sec (*2ms) 01
04-11 ACI Analog Input Bias
0.00～100.00 %
0.00
00: Positive bias
04-12 ACI Bias Polarity
01: Negative bias
00
04-13 ACI Input Gain 1 to 200 % 100
00: No ACI Negative bias command
01: Negative bias, REV motion enabled
04-14
ACI Negative Bias, Reverse
Motion Enable
02: Negative bias, REV motion disabled
00
04-15 AUI Analog Input Bias
0.00～100.00 %
0.00
00: Positive bias
04-16 AUI Bias Polarity
01: Negative bias
00
04-17 AUI Input Gain 1 to 200 % 100
00: No AUI Negative bias command
01: Negative bias, REV motion enabled
04-18
AUI Negative Bias
Reverse Motion Enabled
02: Negative bias, REV motion disabled
00
04-19 AVI Analog Input Delay
0.00 to 10.00 Sec
0.05
04-20 ACI Analog Input Delay
0.00 to 10.00 Sec
0.05
04-21 AUI Analog Input Delay
0.00 to 10.00 Sec
0.05
00: 0.01Hz
04-22
Analog Input Frequency
Resolution
01: 0.1Hz
01
04-23
Gear Ratio for Simple Index
Function
4 ~ 1000
200
04-24
Index Angle for Simple Index
Function
0.0 ~360.0
180.0
04-25
Deceleration Time for Simple
Index Function
0.00 ~100.00
0.00
To Next Page
