Page #20 background imageLoading...
Page #20 background image
VFD-B Series
DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED
3-8
Terminal Symbols Terminal Functions Factory Settings
RA
Multi-function Relay output
(N.O.) a
RB
Multi-function Relay output
(N.C.) b
RC
Multi-function Relay common
Resistor Load
5A(N.O.)/3A(N.C.) 240VAC
5A(N.O.)/3A(N.C.) 24VDC
Inductive Load
1.5A(N.O.)/0.5A(N.C.) 240VAC
1.5A(N.O.)/0.5A(N.C.) 24VDC
Refer to Pr.03-01 to Pr.03-03
MO1
Multi-function output 1
(Photocoupler)
MO2
Multi-function output 2
(Photocoupler)
MO3
Multi-function output 3
(Photocoupler)
Maximum 48VDC, 50mA
Refer to Pr.03-01 to Pr.03-03
MCM
Multi-function output common
Maximum 48VDC, 50mA
+10V
Potentiometer output power
source
+10V 20mA
AVI Analog voltage Input
0 to +10V
ACI Analog current Input
4 to 20mA
AUI
Auxiliary analog voltage input -10 to +10V
AFM
Analog output meter 0 to 10V, 2mA
ACM
Analog control signal
(common)
* Control signal wiring size: 18 AWG (0.75 mm
2
).
