Delta VFD037CP43B-21

Chapter 11 Summary of Parameter SettingsCP2000
11-18
Pr. Parameter Name Setting Range Default
 03-51 AVI1 lowest point
Pr.03-28 = 0, 0.00–10.00 V
Pr.03-28 = 1, 0.00–20.00 mA
Pr.03-28 = 2, 0.00–20.00 mA
0.00
0.00
4.00
 03-52 AVI1 proportional lowest point -100.00–100.00% 0.00
 03-53 AVI1 mid-point
Pr.03-28 = 0, 0.00–10.00 V
Pr.03-28 = 1, 0.00–20.00 mA
Pr.03-28 = 2, 0.00–20.00 mA
5.00
10.00
12.00
 03-54 AVI1 proportional mid-point -100.00–100.00% 50.00
 03-55 AVI1 highest point
Pr.03-28 = 0, 0.00–10.00 V
Pr.03-28 = 1, 0.00–20.00 mA
Pr.03-28 = 2, 0.00–20.00 mA
10.00
20.00
20.00
 03-56 AVI1 proportional highest point -100.00–100.00% 100.00

03-57 ACI lowest point
Pr.03-29 = 0, 0.00–20.00 mA
Pr.03-29 = 1, 0.00–10.00 V
Pr.03-29 = 2, 0.00–20.00 mA
4.00
0.00
0.00
 03-58 ACI proportional lowest point -100.00–100.00% 0.00
 03-59 ACI mid-point
Pr.03-29 = 0, 0.00–20.00 mA
Pr.03-29 = 1, 0.00–10.00 V
Pr.03-29 = 2, 0.00–20.00 mA
12.00
5.00
10.00
 03-60 ACI proportional mid-point -100.00–100.00% 50.00
 03-61 ACI high point
Pr.03-29 = 0, 0.00–20.00 mA
Pr.03-29 = 1, 0.00–10.00 V
Pr.03-29 = 2, 0.00–20.00 mA
20.00
10.00
20.00
 03-62 ACI proportional highest point -100.00–100.00% 100.00

03-63
Positive AVI2 voltage lowest
point
0.00–10.00 V 0.00

03-64
Positive AVI2 voltage
proportional lowest point
-100.00–100.00% 0.00
 03-65 Positive AVI2 voltage mid-point 0.00–10.00 V 5.00
 03-66
Positive AVI2 voltage
proportional mid-point
-100.00–100.00% 50.00

03-67
Positive AVI2 voltage highest
point
0.00–10.00 V 10.00
 03-68
Positive AVI2 voltage
proportional highest point
-100.00–100.00% 100.00
