Chapter 12 Description of Parameter SettingsCP2000
12.1-14-2

Extension Card Output Terminal Selection (AO10)

Extension Card Output Terminal Selection (AO11)
Default: 0
Settings 0–23
 Refer to the function chart below for details setting.
Function Chart
Settings Functions Descriptions
0
Output frequency (Hz) Maximum frequency Pr.01-00 is processed as 100%.
1 Frequency command (Hz) Maximum frequency Pr.01-00 is processed as 100%.
2 Motor speed (Hz) Maximum frequency Pr.01-00 is processed as 100%.
3 Output current (rms) (2.5 ᵡ rated current) is processed as 100%
4 Output voltage (2 ᵡ rated voltage) is processed as 100%
5 DC bus voltage 450V (900V)=100%
6 Power factor -1.000–1.000=100%
7 Power (2 ᵡ rated power) is processed as 100%
9 AVI1 0–10 V = 0–100%
10 ACI 4–20 mA = 0–100%
11 AVI2 -10–10 V = 0–100%
20 CANopen analog output
For CANopen communication analog output
Terminal
Corresponding
address
AFM1 2026-A1
AFM2 2026-A2
AO10 2026-AB
AO11 2026-AC
21 RS-485 analog output
For RS-485 (InnerCOM / Modbus) analog output
Terminal
Corresponding
address
AFM1 26A0H
AFM2 26A1H
AO10 26AAH
AO11 26ABH
22
Communication card
analog output
For communication analog output (CMC-EIP01, CMC-PN01,
CMC-DN01)
Terminal
Corresponding
address
AFM1 26A0H
AFM2 26A1H
AO10 26AAH
AO11 26ABH
23 Constant voltage output
Pr.14-20 and Pr.14-21 control voltage output level
0–100% of Pr.14-20 corresponds to 0–10 V of AO10.
0–100% of Pr.14-21 corresponds to 0–10 V of AO11.
