Delta VFD110CP43B-21 User Manual

Chapter 12 Description of Parameter SettingsCP2000
12.1-00-2
460V Series
Frame D0 D E F G H
kW 45 55 75 90 110 132 160 185 220 280 315 355 400 500
HP 60 75 100 125 150 175 215 250 300 375 425 475 536 675
Identity code 29 31 33 35 37 39 41 43 45 47 49 51 53 55
Rated current for
light load [A]
91 110 150 180 220 260 310 370 460 530 616 683 770 930
Rated current for
normal load [A]
73 91 110 150 180 220 260 310 370 460 550 616 683 866
575V Series
Frame A B
kW 1.5 2.2 3.7 5.5 7.5 11 15
HP 2 3 5 7.5 10 15 20
Identity code 505 506 507 508 509 510 511
Rated current for
light load [A]
3 4.3 6.7 9.9 12.1 18.7 24.2
Rated current for
normal load [A]
2.5 3.6 5.5 8.2 10 15.5 20
690V Series
Frame C D E
kW 18.5 22 30 37 45 55 75 90 110 132
HP 25 30 40 50 60 75 100 125 150 175
Identity code 612 613 614 615 616 617 618 619 620 621
Rated current for
light load [A]
24 30 36 45 54 67 86 104 125 150
Rated current for
normal load [A]
20 24 30 36 45 54 67 86 104 125
Frame F G H
kW 160 200 250 315 400 450 560 630
HP 215 270 335 425 530 600 745 840
Identity code 622 686 687 626 628 629 631 632
Rated current for
light load [A]
180 220 290 350 430 465 590 675
Rated current for
normal load [A]
150 180 220 290 350 385 465 675
Parameter Reset
Default: 0
Settings 0: No Function
1: Write protection for parameters
5: Reset kWh display to 0
6: Reset PLC (including CANopen Master Index)
7: Reset CANopen Index (Slave)
9: Reset all parameters to defaults with base frequency at 50 Hz
10: Reset all parameters to defaults with base frequency at 60 Hz
