Chapter 12 Description of Parameter SettingsCP2000
12.1-00-3
When set to 1, all parameters are read only except Pr.00-02, Pr.00-07 and Pr.00-08. Set Pr.00-02
to 0 before changing other parameter settings.
When set to 5, kWh displayed value can be reset to 0 even when the drive is operating. Pr.05-26,
Pr.05-27, Pr.05-28, Pr.05-29 and Pr.05-30 are reset to 0.
When set to 6, clear internal PLC program (includes the related settings of PLC internal CANopen
master)
When set to 7, reset the related settings of CANopen slave.
When set to 9 or 10, reset all parameters to defaults. If there is a password set in Pr.00-08, enter
the password set in Pr.00-07 to reset to default.
When it is set to 6, 7, 9 and 10, reboot the motor drive after setting.
Start-up Display Selection
Default: 0
Settings 0: F (Frequency command)
1: H (Output frequency)
2: U (User defined)
3: A (Output current)
This parameter determines the start-up display page. This is the user defined choice display
according to the setting in Pr.00-04.
Content of Multi-function Display
Default: 3
Settings 0: Display output current (A) (Unit: Amp)
1: Display counter value (c) (Unit: CNT)
2: Display actual output frequency (H) (Unit: Hz)
3: Display DC bus voltage (v) (Unit: V
DC
)
4: Display output voltage (E) (Unit: V
AC
)
5: Display output power angle (n) (Unit: deg)
6: Display output power in kW (P) (Unit: kW)
7: Display actual motor speed rpm (Unit: rpm)
10: Display PID feedback (b) (Unit: %)
11: Display AVI1 in % (1.) (Unit: %)
12: Display ACI in % (2.) (Unit: %)
13: Display AVI2 in % (3.) (Unit: %)
14: Display the temperature of IGBT (i.) (Unit: °C)
15: Display the temperature of capacitance (c.) (Unit: °C)
16: The status of digital input (ON/OFF) (i)
17: The status of digital output (ON/OFF) (o)
18: Multi-step speed (S)
19: The corresponding CPU pin status of digital input (d)
20: The corresponding CPU pin status of digital output (0.)
26: Ground Fault GFF (G.) (Unit: %)
To Next Page
