Chapter 12 Description of Parameter SettingsCP2000
12.1-09-9
Modbus
address
R/W Function
2101H R
bit1–0
AC motor drive operation status
00B: Drive stops
01B: Drive decelerating
10B: Drive standby
11B: Drive operating
bit2
1：JOG Command
bit4–3
Operation Direction
00B: FWD run
01B: From REV run to FWD run
10B: From FWD run to REV run
11B: REV run
bit8 1: Master frequency controlled by communication interface
bit9 1: Master frequency controlled by analog/external signal
bit10 1: Operation command controlled by communication interface
bit11 1: Parameter locked
bit12 1: Enable to copy parameters from keypad
bit15–13 Reserved
2102H R Frequency command (XXX.XX Hz)
2103H R Output frequency (XXX.XX Hz)
2104H R
Output current (XX.XX A). When current is higher than 655.35, it shifts the
decimal as (XXX.X A). The decimal can refer to High byte of 211F.
2105H R DC bus Voltage (XXX.X V)
2106H R Output voltage (XXX.X V)
2107H R Current step number of multi-step speed operation
2108H R Reserved
2109H R Counter value
210AH R Power factor angle (XXX.X)
210CH R Actual motor speed (XXXXX rpm)
210DH R Reserved
210EH R Reserved
210FH R Power output (X.XXX kW)
2116H R Multi-function display (Pr.00-04)
211BH R
Maximum Operation Frequency (Pr.01-00) or Maximum User-defined Value
(Pr.00-26)
When Pr.00-26 is 0, this value is equal to Pr.01-00 setting
When Pr.00-26 is not 0, and the command source is keypad, this value =
Pr.00-24 * Pr.00-26 / Pr.01-00
When Pr.00-26 is not 0, and the command source is 485, this value =
Pr.09-10 * Pr.00-26 / Pr.01-00
211FH R High byte: decimal of current value (display)
Status monitor read only (22xx)
Modbus
address
RW Function
2200H R
Display output current (A). When current is higher than 655.35, it shifts the
decimal as (XXX.X A). The decimal can refer to High byte of 211F.
2201H R Display counter value ©
2202H R Actual output frequency (XXXXX Hz)
2203H R DC bus voltage (XXX.X V)
2204H R Output voltage (XXX.X V)
2205H R Power angle (XXX.X)
