Chapter 12 Description of Parameter SettingsCP2000
12.1-09-10
Modbus
address
RW Function
2206H R Display actual motor speed kW of U, V, W (XXXX.X kW)
2207H R
Display motor speed in rpm estimated by the drive or encoder feedback
(XXXXX rpm)
2208H R
Display positive/negative output torque in %, estimated by the drive (XXX.X
%)
2209H R Reserved
220AH R PID feedback value after enabling PID function (XXX.XX %)
220BH R
Display signal of AVI1 analog input terminal, 0–10 V corresponds to
0.00–100.00% (1.) (see NOTE 2 in Pr.00-04)
220CH R
Display signal of ACI analog input terminal, 4–20 mA / 0–10 V corresponds
to 0.00–100.00% (2.) (see NOTE 2 in Pr.00-04)
220DH R
Display signal of AVI2 analog input terminal, -10 V–10 V corresponds to
-100.00–100% (3.) (see NOTE 2 in Pr.00-04)
220EH R IGBT temperature of drive power module (XXX.X°C)
220FH R The temperature of capacitance (XXX.X°C)
2210H R
The status of digital input (ON/OFF), refer to Pr.02-12
(see NOTE 3 in Pr.00-04)
2211H R
The status of digital output (ON/OFF), refer to Pr.02-18
(see NOTE 4 in Pr.00-04)
2212H R The multi-step speed that is executing (S)
2213H R
The corresponding CPU pin status of digital input (d.)
(see NOTE 3 in Pr.00-04)
2214H R
The corresponding CPU pin status of digital output (O.)
(see NOTE 4 in Pr.00-04)
2215H R Reserved
2216H R Reserved
2217H R Reserved
2218H R Reserved
2219H R Display times of counter overload (XXX.XX %)
221AH R GFF (XXX.XX %)
221BH R DC bus voltage ripples (XXX.X V)
221CH R PLC register D1043 data (C)
221DH R Reserved
221EH R User page displays the value in physical measure
221FH R Output Value of Pr.00-05 (XXX.XX Hz)
2220H R
Number of motor turns when drive operates (saves when drive stops, and
resets to zero when operating)
2221H R
Operating position of the motor (saves when drive stops, and resets to zero
when operating)
2222H R Fan speed of the drive (XXX %)
2223H R Control mode of the drive 0: speed mode
2224H R Carrier frequency of the drive (XXXX kHz)
2225H R Reserved
2226H R
Drive
status
bit1–0
00b: No direction
01b: Forward
10b: Reverse
bit3–2
01b: Drive ready
10b: Error
bit4
0b: Motor drive did not output
1b: Motor drive did output
bit5
0b: No alarm
1b: Alarm
2228H R Reserve
