Chapter 11 Summary of Parameter Settings | VFD-ED
11-4
Pr. Parameter Name Setting Range Default
VF
VFPG
SVC
FOCPG
FOCPM
18: Display the step speed of multi-step speed
that is executing (S)
19: The corresponding CPU digital input pin
status (i.)
20: The corresponding CPU digital output pin
status (o.)
21–23: Reserved
24: Output AC voltage when malfunction
occurred (E) (Unit: V
AC
)
25: Output DC voltage when malfunction
occurred (v) (Unit: V
DC
)
26: Motor frequency when malfunction
occurred (H) (Unit: Hz)
27: Output current when malfunction occurred
(A) (Unit: Amp)
28: Output frequency when malfunction
occurred (F) (Unit: Hz)
29: Frequency command when malfunction
occurred (F) (Unit: Hz)
30: Output power when malfunction occurred
(P) (Unit: kW)
31: Output torque when malfunction occurred
(t) (Unit: %)
32: Input terminal status when malfunction
occurred (i)
33: Output terminal status when malfunction
occurred (o)
34: Drive status when malfunction occurred (s)
35: Display MI and MO status on digital keypad
36: CAN communication interference index (c)
(Unit: %)
37: Multi-function display selection (q) (Unit: %)
40: Elevator actual speed (Unit: m/s)
 00-05
User-Defined
Coefficient K
Digit 4: number of decimal points (0–3)
Digit 3–0: 40–9999
0 ○ ○ ○ ○ ○
00-06
Software Version
READ ONLY
##.##
○
○
○
○
○
 00-07 Password Input
1–9998, 10000–65535
0–2: number of wrong password attempts
0 ○ ○ ○ ○ ○
 00-08 Password Set
1–9998, 10000–65535
0: No password set or successful input in
Pr.00-07
1: Password has been set
0 ○ ○ ○ ○ ○
00-09 Control Method
0: V/F control (V/F)
1: V/F control + Encoder (VFPG)
2: Sensorless Vector Control (SVC)
3: FOC vector control + Encoder (FOCPG)
0 ○ ○ ○ ○ ○
