Chapter 12 Descriptions of Parameter SettingsC2000 Plus
12.1-01-4
 5: You can return the kWh displayed value to 0 even during drive operation. For example, you can
set Pr.05-26–Pr.05-30 to 0.
 6: Clear the internal PLC program (includes the related settings of PLC internal CANopen master)
 7: Reset the related settings of CANopen slave.
 9 or 10: Reset all parameters to defaults. If you have set a password (Pr.00-08), unlock the
password (Pr.00-07) to clear the password you have set before you reset all parameters.
 For settings of 6, 7, 9, 10, you must reboot the motor drive after you finish the setting.

00-03
Start-Up Display
Default: 0
Settings 0: F (frequency command)
1: H (output frequency)
2: U (user-defined, see Pr.00-04)
3: A (output current)
 Determines the start-up display page after power is applied to the drive. The user-defined
contents display according to the Pr.00-04 settings.

00-04
Content of Multi-Function Display (User-Defined)
Default: 3
Settings 0: Display output current (A) (unit: Amp)
1: Display counter value (c) (Unit: CNT)
2: Display the motor’s actual output frequency (H.) (Unit: Hz)
3: Display the drive’s DC bus voltage (v) (Unit: V
DC
)
4: Display the drive’s output voltage (E) (Unit: V
AC
)
5: Display the drive’s output power angle (n) (Unit: deg)
6: Display the drive’s output power (P) (Unit: kW)
7: Display the motor speed rpm (r) (Unit: rpm)
8: Display the drive’s estimated output torque, motor’s rated torque is 100%
(t) (Unit: %)
9: Display PG feedback (G) (refer to Pr.10-00 and Pr.10-01) (Unit: PLS)
10: Display PID feedback (b) (Unit: %)
11: Display AVI analog input terminal signal (1.) (Unit: %)
12: Display ACI analog input terminal signal (2.) (Unit: %)
13: Display AUI analog input terminal signal (3.) (Unit: %)
14: Display the drive’s IGBT temperature (i.) (Unit: °C)
15: Display the drive’s capacitance temperature (c.) (Unit: °C)
16: The digital input status (ON / OFF) (i)
17: The digital output status (ON / OFF) (o)
18: Display multi-step speed (S)
19: The corresponding CPU digital input pin status (d)
20: The corresponding CPU digital output pin status (0.)
