Chapter 11 Summary of Parameter SettingsME300
11-25
Pr. Explanation Settings Default
06-26 Fault output option 4 0–65535 (refer to bit table for fault code) 0
06-27
Electronic thermal relay
selection (motor 2)
0: Inverter motor (with external forced cooling)
1: Standard motor (motor with fan on shaft)
2: Disable
2
06-28
Electronic thermal relay
action time (motor 2)
30.0–600.0 sec.
60.0
06-29 PTC detection selection
0: Warn and continue operation
1: Warn and ramp to stop
2: Warn and coast to stop
3: No warning
0
06-30 PTC level 0.0–100.0%
50.0
06-31
Frequency command for
malfunction
0.00–599.00 Hz Read only
06-32
Output frequency at
malfunction
0.00–599.00 Hz Read only
06-33
Output voltage at
malfunction
0.0–6553.5 V Read only
06-34 DC voltage at malfunction 0.0–6553.5 V Read only
06-35
Output current at
malfunction
0.00–655.35 Amp Read only
06-36
IGBT temperature at
malfunction
0.0–6553.5
o
C Read only
06-38
Motor speed at
malfunction
0–65535 rpm Read only
06-40
Status of the
multi-function input
terminal at malfunction
0000h–FFFFh Read only
06-41
Status of the
multi-function output
terminal at malfunction
0000h–FFFFh Read only
06-42
Drive status at
malfunction
0000h–FFFFh Read only
06-44 STO latch selection
0: STO Latch
1: STO No Latch
0
06-45
Output phase loss
detection (OPHL) action
0: Warn and continue operation
1: Warn and ramp to stop
2: Warn and coast to stop
3: No warning
3
06-46
Detection time of output
phase loss
0.000–65.535 sec.
0.500
