Chapter 7 Optional AccessoriesME300
7-49
Frame C
Screw Torque
M4
14–16 kg-cm / [12.4–13.9 lb-in.] / [1.37–1.57 Nm]
M5
16–20 kg-cm / [13.9–17.4 lb-in.] / [1.57–1.96 Nm]
Unit: mm [inch]
