7-2 Magnetic Contactor / Air Circuit Breaker and Non-fuse Circuit Breaker
Magnetic Contactor (MC) and Air Circuit Breaker (ACB)
It is recommended the surrounding temperature for MC should be ≥ 60°C and that for ACB should be ≥
50°C. In the meanwhile, consider temperature derating for components with ON / OFF switch in
accordance with the ambient temperature of the on-site distribution panel.
115V Models
Frame Model
Heavy Duty
Output Current [A]
Heavy Duty
Input Current [A]
MC/ACB Selection
[A]
A
VFD1A6MS11ANSAA 6 1.6 11
VFD2A5MS11ANSAA 9.4 2.5 18
C
VFD4A8MS11ANSAA 18 4.8 32
Table 7-2-1
230V Models
Frame Model
Heavy Duty
Output Current [A]
Heavy Duty
Input Current [A]
MC/ACB Selection
[A]
A
VFD1A6MS21ANSAA 5.1 1.6 9
VFD2A8MS21ANSAA 7.3 2.8 13
VFD1A6MS23ANSAA 1.9 1.6 9
VFD2A8MS23ANSAA 3.4 2.8 9
VFD4A8MS23ANSAA 5.8 4.8 11
B
VFD1A6MS21AFSAA 5.1 1.6 9
VFD2A8MS21AFSAA 7.3 2.8 13
VFD4A8MS21AFSAA 10.8 4.8 18
VFD4A8MS21ANSAA 10.8 4.8 18
VFD7A5MS23ANSAA 9 7.5 18
C
VFD7A5MS21ANSAA 16.5 7.5 32
VFD11AMS21ANSAA 24.2 11 40
VFD7A5MS21AFSAA 16.5 7.5 32
VFD11AMS21AFSAA 24.2 11 40
VFD11AMS23ANSAA 13.2 11 22
VFD17AMS23ANSAA 20.4 17 32
D
VFD25AMS23ANSAA 30 25 55
E
VFD33AMS23ANSAA 39.6 33 65
VFD49AMS23ANSAA 58.8 49 105
F
VFD65AMS23ANSAA 78 65 130
Table 7-2-2
