Chapter 7 Optional AccessoriesMS300
7-15
Model
Rated
Current
[Arms]
Saturation
Current
[Arms]
Input / Output
Reactor [mH]
Input Reactor
Delta Part #
Output
Reactor
Delta Part #
DC
Reactor
[mH]
DC Reactor
Delta Part #
VFD33AMS23ANSAA
VFD33AMS23ENSAA
36 54 0.216 DR049AP215 DR049LP215 0.851 DR033DP851
VFD49AMS23ANSAA
VFD49AMS23ENSAA
51 76.5 0.216 DR049AP215 DR049LP215 0.574 DR049DP574
VFD65AMS23ANSAA
VFD65AMS23ENSAA
69 103.5 0.169 DR075AP170 DR075LP170 0.432 DR065DP432
Table 7-4-5
230V, 50–60 Hz / Three-phase - Heavy Duty
Model
Rated
Current
[Arms]
Saturation
Current
[Arms]
Input / Output
Reactor [mH]
Input Reactor
Delta Part #
Output
Reactor
Delta Part #
DC
Reactor
[mH]
DC Reactor
Delta Part #
VFD1A6MS23ANSAA
VFD1A6MS23ENSAA
1.6 3.2 2.536 DR005A0254 DR005L0254 5.857 DR005D0585
VFD2A8MS23ANSAA
VFD2A8MS23ENSAA
2.8 5.6 2.536 DR005A0254 DR005L0254 5.857 DR005D0585
VFD4A8MS23ANSAA
VFD4A8MS23ENSAA
4.8 9.6 2.536 DR005A0254 DR005L0254 5.857 DR005D0585
VFD7A5MS23ANSAA
VFD7A5MS23ENSAA
7.5 15 1.585 DR008A0159 DR008L0159 3.66 DR008D0366
VFD11AMS23ANSAA
VFD11AMS23ENSAA
11 22 1.152 DR011A0115 DR011L0115 2.662 DR011D0266
VFD17AMS23ANSAA
VFD17AMS23ENSAA
17 34 0.746 DR017AP746 DR017LP746 1.722 DR017D0172
VFD25AMS23ANSAA
VFD25AMS23ENSAA
25 50 0.507 DR025AP507 DR025LP507 1.172 DR025D0117
VFD33AMS23ANSAA
VFD33AMS23ENSAA
33 66 0.32 DR033AP320 DR033LP320 0.851 DR033DP851
VFD49AMS23ANSAA
VFD49AMS23ENSAA
46 92 0.216 DR049AP215 DR049LP215 0.574 DR049DP574
VFD65AMS23ANSAA
VFD65AMS23ENSAA
65 130 0.163 DR065AP162 DR065LP162 0.432 DR065DP432
Table 7-4-6
460V, 50–60 Hz / Three-phase - Normal Duty
Model
Rated
Current
[Arms]
Saturation
Current
[Arms]
Input / Output
Reactor [mH]
Input Reactor
Delta Part #
Output
Reactor
Delta Part #
DC
Reactor
[mH]
DC Reactor
Delta Part #
VFD1A5MS43ANSAA
VFD1A5MS43ENSAA
VFD1A5MS43AFSAA
1.8 2.7 8.102 DR003A0810 DR003L0810 18.709 DR003D1870
VFD2A7MS43ANSAA
VFD2A7MS43ENSAA
VFD2A7MS43AFSAA
3 4.5 6.077 DR004A0607 DR004L0607 18.709 DR003D1870
VFD4A2MS43AFSAA
VFD4A2MS43ANSAA
VFD4A2MS43ENSAA
4.6 6.9 4.05 DR006A0405 DR006L0405 14.031 DR004D1403
VFD5A5MS43AFSAA
VFD5A5MS43ANSAA
VFD5A5MS43ENSAA
6.5 9.75 2.7 DR009A0270 DR009L0270 9.355 DR006D0935
VFD7A3MS43ANSAA
VFD7A3MS43ENSAA
VFD7A3MS43AFSAA
8.9 13.35 2.7 DR009A0270 DR009L0270 6.236 DR009D0623
