Delta VFD4A8MS23ANSAA User Manual

Chapter 11 Summary of Parameter SettingsMS300
244
Pr.
Explanation
Settings
Default

08-16
PID Compensation
Selection
0: Parameter setting
1: Analog input
0

08-17
PID Compensation
-100.0–100.0%
0
08-18
Sleep Mode Function
Setting
0: Refer to PID output command
1: Refer to PID feedback signal
0

08-19
Wake-Up Integral Limit
0.0–200.0%
50.0
08-20
PID Mode Selection
0: Serial connection
1: Parallel connection
0
08-21
Enable PID to Change the
Operation Direction
0: Operation direction cannot be changed
1: Operation direction can be changed
0

08-22
Wake-Up Delay Time
0.00–600.00 sec.
0.00

08-23
PID Control Flag
bit 0 = 1: PID running in reverse follows the setting for
Pr.00-23.
bit 0 = 0: PID running in reverse refers to PID’s
calculated value.
bit 1 = 1: two decimal places for PID Kp
bit 1 = 0: one decimal place for PID Kp
2

08-26
PID Output Command
Limit (Reverse Limit)
0.0–100.0%
100.0

08-27
Acceleration / Deceleration
Time for PID Command
0.00–655.35 sec.
0.00

08-29
Frequency Base
Corresponding to
100.00% PID
0: PID control output 100.00% corresponding to
maximum operation frequency (Pr.01-00)
1: PID control output 100.00% corresponding to the input
value of the auxiliary frequency
0

08-31
Proportional Gain 2
0.0–1000.0 (when Pr.08-23 setting bit1 = 0)
0.00–100.00 (when Pr.08-23 setting bit1 = 1)
1.00

08-32
Integral Time 2
0.00–100.00 sec.
1.00

08-33
Differential Time 2
0.00–1.00 sec.
0.00

08-65
PID Target Value Source
0: Frequency command (Pr.00-20, Pr.00-30)
1: Pr.08-66 setting
2: RS-485 communication input
3: External analog input (refer to Pr.03-00, Pr.03-01)
4: CANopen communication card
6: Communication card (does not include CANopen card)
7: Digital keypad potentiometer knob
0

08-66
PID Target Value Setting
-100.00–100.00%
50.00

08-67
Master and Auxiliary
Reverse Running Cutoff
Frequency
0.0–100.0%
10.0
