CONN 2 12 pin
CONN 1 10 pin
Installation option B:
B-1. Pass the I/O extension kit cable through the cabling hole.
1/2” Pipe
A-4. Secure the 1/2" conduit pipe using the side-routing bracket. You can then route cables
and install the camera and base plate to the bracket.
