DEMA ATLAS 844P
™
SERIES
LAUNDRY CONTROL
I-907 Page 15 of 17
Rev. C-33371
NO. QTY. DEMA NO. DESCRIPTION
1 4 81-20-1 #4 HI-LO SCREW
2 1 84-153-1 CONTROL BOARD AND DISPLAY ASSY.
3 1 81-147-1 KEY PAD
5 1 81-139-1 CONTROL COVER
6 11 44-116-2 #8 X 3/8" HI-LO SCREW
7 1 81-137-1 FIREWALL
8 4 41-63-10 #8-32 X 1 3/4 PHIL. SS SCREW
10 1 81-138-1 POWER SUPPLY BRACKET
11 1 84-154-1 POWER SUPPLY (includes 84-xxx-x power supply cable)
12 1 84-125-1 POWER SUPPLY CABLE
13 8 44-116-1 #8 X 1/2 HI-LO SCREW
14 1 81-170-1 ENCLOSURE ASSY. BACK
15 7 81-47-1 1/2" HOLE PLUG
16 1 81-187-1 MOUNTING BRACKET
17 5 41-40-2 #6-32 X 1/2 PHIL SS SCREW
18 1 81-168-1 ENCLOSURE ASSY.
19 1 81-186-11 LARGE ACCESS PANEL ASSY.
20 1
1
81-186-5
81-186-7
SMALL ACCESS PANEL ASSY. W/TWO HOLE PLUGS
SMALL ACCESS PANEL ASSY. W/CONDUIT FITTING
21 1 81-148-3 CONDUIT FITTING
22 2 81-47-6 1" HOLE PLUG
23 1 81-47-5 3/4” HOLE PLUG
24 1 81-16 LIQUID-TIGHT FEED THROUGH
25 1 81-47-4 7/8” HOLE PLUG
26 2 81-159-1 GASKET - PUMP BASE
28 2 – 6
2 – 6
81-173-5
81-173-1
PUMP 2 SPRING 1/4” ID – 105RPM
PUMP 2 SPRING 1/4" ID – 60RPM
29 6 81-19-7 #8 SCREW ( HINGE SCREW)
30 1 81-140-1 HINGE
31 2 81-29-2 CAPTIVE SCREW
32 1 L942 DISPLAY LABEL
33 1 L941 ATLAS LABEL
35 2 81-32-44 RED CABLE ASSEMBLY
36 2 81-32-43 BLACK CABLE ASSEMBLY
38 1 81-198-4 PUMP MODULE ASSY. W / 2 SPRING ¼” ID 105 RPM
PUMP
39 2 81-144-1 SIDE MODULE JOINT
40 1 81-173-1 DETERGENT PUMP - 60 RPM (SEE BREAKOUT
DRAWING)
44 4 81-193-1 SPACER
