Parameter Settings:
I²S Pin-Out Configuration:
1. Press SETUP button once, SETUP LED on. Arce Streamer in Setting Mode
2. In Setting Mode, the push buttons and LEDs on the front panel represent a different
meaning.
Button
On
I2S/USB
Setting Selection – Left
SOURCE
Setting Selection – Right
3. Press I2S/USB or SOURCE button. The Streaming Service LED will turn on/off
according. Stop when ‘roon’ LED is turned on. You are in I2S Setting Mode as the
‘roon’ LED on.
4. Toggle the LOCAL button momentarily, I2S/NET/LOCAL will turn on/off in a fixed
pattern to denote binary 000-111
5. Set the I2S Pinout to 000
6. Wait for 5s or Press the SETUP button once again to exit Setting Mode
7. STREAMER back in operational mode
I²S Pinout Configuration
MODE
LED
I2S PINOUT
I2S
NET
LOCAL
PIN
DATA
BCK
LRCK
DATA
BCK
LRCK
MODE
1
3
4
6
7
9
0
0
0
0
0
DATA-
DATA+
BCK+
BCK-
LRCK-
LRCK+
1
1
0
0
1
DATA+
DATA-
BCK+
BCK-
LRCK-
LRCK+
2
0
1
0
2
DATA-
DATA+
BCK-
BCK+
LRCK-
LRCK+
3
1
1
0
3
DATA+
DATA-
BCK-
BCK+
LRCK-
LRCK+
4
0
0
1
4
DATA-
DATA+
BCK+
BCK-
LRCK+
LRCK-
5
1
0
1
5
DATA+
DATA-
BCK+
BCK-
LRCK+
LRCK-
6
0
1
1
6
DATA-
DATA+
BCK-
BCK+
LRCK+
LRCK-
7
1
1
1
7
DATA+
DATA-
BCK-
BCK+
LRCK+
LRCK-
Table 1. I2S PINOUT CONFIGURATION
