DENAFRIPS ARCE - I2 S DSD L;R Channel Configuration; External Clock Configuration

© DENAFRIPS CO. LTD. & VINSHINE AUDIO PTE. LTD. (SINGAPORE)
ALL RIGHTS RESERVED
I²S DSD L/R Channel Configuration:
1. Press SETUP button once, SETUP LED on. Arce Streamer in Setting Mode
2. In Setting Mode, the push buttons and LEDs on the front panel represent a different
meaning.
Button
On
I2S/USB
Setting Selection – Left
SOURCE
Setting Selection – Right
3. Press I2S/USB or SOURCE button. The Streaming Service LED will turn on/off
according. Stop when ‘DLNA’ LED is turned on. You are in I2S DSD L/R Channel
Setting Mode as the ‘DLNA’ LED on.
4. Toggle the LOCAL button momentarily, LOCAL LED will turn on/off.
• LOCAL LED Off – I2S DSD Channel Norm
• LOCAL LED On – I2S DSD Channel Swap
5. Wait for 5s or Press the SETUP button once again to exit Setting Mode
6. STREAMER back in operational mode
External Clock Configuration:
1. Press SETUP button once, SETUP LED on. Arce Streamer in Setting Mode
2. In Setting Mode, the push buttons and LEDs on the front panel represent a different
meaning.
Button
On
I2S/USB
Setting Selection – Left
SOURCE
Setting Selection – Right
3. Press I2S/USB or SOURCE button. The Streaming Service LED will turn on/off
according. Stop when ‘Airplay’ LED is turned on. You are in External Clock Setting
Mode as the ‘Airplay’ LED on.
4. Toggle the LOCAL button momentarily, NET LED will turn on/off.
• NET LED Off – Arce uses internal clock
• NET LED On – Arce uses external clock
5. Wait for 5s or Press the SETUP button once again to exit Setting Mode
6. STREAMER back in operational mode
