4. Product description
4.1 Intended use
The bio.x parts cleaning unit is used to clean oil and grease from work pieces in an efficient, environmentally
sustainable way using exclusively cleaning fluids authorised by DENIOS.
Other detergents such as degreasers or alkali cleaning agents must not
be used!
Solvents, disinfectants, alkali or acidic fluids, carburettor and diesel fuels or turpentine must not be
poured into the appliance.
4.2 Layout and how it works
Item Description
Mat.
No.
Item Description Mat. No.
1 Base with tank - 15 Mounting plate 151683
2 Stand top - 16 Filter insert 135348
3 Ball valve 135279 17 Lid set (optional) 135148
4 Control unit 169678 Aerator 230 V 135310
Heating system 230 V 177340
18
Aerator 115 V 138350
5
Heating system 115 V 177342
19
Screw-on connecting piece
G3/8“
135301
Pump 230 V 134979 20 Connector assembly AD 3/8“ 135304
6
Pump 115 V 134976 21 Tubular pin insert AD 3/8“ 135306
7 Level switch 135274 Power cable 230 V 160517
8 PT 100 temperature sensor 135266
22
Power cable 115 V 142016
9 Brush 135277 23 Screw-on pump 135302
10 Flexible hose with flat nozzle 135289 24 Air hose 175289
11 600 µm filter screen 135256 25 Aerator 138281
12 Coarse filter 135255 26 Brush hose 151100
13 Filter bracket 160677 27 O-ring for filter 150609
14 Filter set (optional) 135149 28 Plug 153098
