Denon AVC-X3800H User Manual

Inserting the batteries
1
Remove the rear lid in the direction of the arrow and
remove it.
2
Insert two batteries correctly into the battery
compartment as indicated.
Batteries
3
Put the rear cover back on.
NOTE
0
To prevent damage or leakage of battery fluid:
0
Do not use a new battery together with an old one.
0
Do not use two different types of batteries.
0
Remove the batteries from the remote control unit if it will not be in use for long
periods.
0
If the battery fluid should leak, carefully wipe the fluid off the inside of the battery
compartment and insert new batteries.
Operating range of the remote control
unit
Point the remote control unit at the remote sensor when operating it.
30° 30°
Approx. 7 m
Contents
Connections Playback Settings Tips Appendix
9
Front panel Display Rear panel Remote Index

Denon AVC-X3800H Specifications

General

Channels	9.4
Power Output per Channel (8 ohms, 20Hz-20kHz, 0.08% THD, 2ch driven)	105 W
Power Output per Channel (6 ohms, 1kHz, 0.7% 2ch driven)	135 W
Speaker Impedance	4-16 ohms
Input Sensitivity/Impedance	200 mV / 47 kohms
Signal-to-Noise Ratio	102 dB
HDMI Outputs	3
HDMI 2.1 Support	Yes
8K/60Hz Pass-through	Yes
4K/120Hz Pass-through	Yes
HDR Support	HDR10, HDR10+, Dolby Vision, HLG
eARC Support	Yes
Dolby Atmos	Yes
DTS:X	Yes
Auro-3D	Yes
IMAX Enhanced	Yes
Audyssey MultEQ XT32	Yes
HEOS Built-in	Yes
Wi-Fi	Yes
Bluetooth	Yes
AirPlay 2	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Phono Input	Yes
Network Connectivity	Ethernet, Wi-Fi
Dimensions (W x H x D)	434 x 167 x 389 mm
Weight	12.5 kg
Amplifier Class	Class AB
Frequency Response	10 Hz - 100 kHz +1, -3 dB (Direct Mode)
Pre-Outs	11.4
Audio Inputs/Outputs	Analog, Digital
HDMI Inputs	6 + 1 (Front)
